Product specifications
Select your size from the options above to see the matching specifications.
Enter the ATM shown on your trailer or caravan compliance plate. ATM means Aggregate Trailer Mass. For example, 2.5 tonnes is 2500 kg. Use the rated ATM, not the weight you normally tow.
Conveying & Hoisting Solutions does not have a storefront open to the general public. However, you may select the Click & Collect option at checkout. We'll notify you when it's ready for pickup.
Official Australian Government component approval to ADR 62/02
Make connecting your caravan or trailer safety chains easier with a rated hook kit that holds Road Vehicle Component Type Approval. No shackle pins to wind in and out every time you hitch up.
Each kit includes two Grade 80 hooks and two reusable QUICKLOCK® connectors and is available in orange or black.
Why choose this kit?
Choose the correct size
Select your kit using the Aggregate Trailer Mass (ATM) on your trailer’s compliance plate, not the trailer’s current loaded weight.
Light kit: up to 2,000 kg ATM
Heavy kit: up to 4,000 kg ATM
Important: Each hook must be suitable for the trailer’s full ATM. Do not add the ratings of two hooks together.
Choose your configuration
Hooks on the vehicle
Fit the hooks to compatible towbar attachment points, then connect your trailer safety chains to the hooks.
Hooks on the trailer chains
Add two matching chain connectors, sold separately, and follow the installation guide.
Trailers over 3,500 kg ATM use Short-link lifting chain.
Add two matching Omega Links, one for each safety chain. Use 10 mm Omega Links with 10 mm chain or 13 mm Omega Links with 13 mm chain. The Heavy kit’s maximum remains 4,000 kg ATM.
Approval and installation
The Light and Heavy hook sets hold Australian Government Road Vehicle Component Type Approval to ADR 62/02. The approval applies to the component. The kit must still be correctly sized and installed with compatible safety chains and attachment points.
View installation guide | View approval documents
Not sure which kit or configuration you need? Call us on 02 9707 2797 before ordering.
We aim to process orders within 1–3 business days. Made-to-order and special-order products may have longer lead times, as shown in the product details.
Delivery options and costs are calculated at checkout. Free shipping applies only where stated on the product.
For full details, see the Shipping Policy linked in our footer.
For warranty information, please see the Warranty page linked in our footer. If you need assistance with a product, contact our online store team on 02 9707 2797 and select option 2.
Select your size from the options above to see the matching specifications.
| Variant | Quantity | Price | Total |
|---|---|---|---|
|
Light Trailer with ATM up to 2,000kg (Grade 80) / Orange
103506
|
|
||
|
Light Trailer with ATM up to 2,000kg (Grade 80) / Black
103506B
|
|
||
|
Heavy Trailer with ATM up to 4,000kg (Grade 80) / Orange
103508
|
|
||
|
Heavy Trailer with ATM up to 4,000kg (Grade 80) / Black
103508B
|
|
